UNI AIR
DC Charger
CCS1/CCS2 DC 160／240／320kW
Compatible・Scalable・Efficient
All-in-One Integration, Outstanding Performance
-
AC input supports TN-S 380/400VAC ±10% 50/60Hz grid
-
Charging interfaces compatible with CCS1 and CCS2, meeting diverse EV requirements
-
Equipped with DC metering and dual DC meters for accuracy and stability
-
Features 300A air-cooled dual connectors, supporting alternating or simultaneous charging
-
Comes with an swing-arm cable management system for smooth and easy operation
INTEGRATED EXCELLENCE
COMPATIBILITY
SUPPORTS 160–320KW, CCS1/CCS2, AND DUAL-GUN CHARGING WITH DUAL DC METERS
SCALABILITY
EXPANDABLE WITH UP TO EIGHT 30–40KW MODULES FOR EASY UPGRADES
AUTHENTICATION
RFID, APP, OR PAYMENT TERMINAL FOR SECURE ACCESS
OPTIMIZED INSTALLATION
COMPACT DESIGN LOWERS INSTALL AND MAINTENANCE COSTS
LOAD BALANCE
AUTO-ADJUSTS POWER FOR EFFICIENT USE FROM SMALL SITES TO LARGE FLEETS
HIGH COMPATIBILITY
-
Supports 160kW / 240kW / 320kW power levels and CCS1/CCS2 connectors, with dual DC meters enabling both alternating and simultaneous dual-gun charging
MODULAR SCALABILITY
-
Adopts a modular cabinet design with up to eight compact 30–40kW modules
-
Expansion only requires partial component replacement and module addition, easily covering 160kW, 180kW, 240kW, and 320kW power demands
VERSATILE AUTHENTICATION
-
Supports RFID, mobile apps, or payment terminals for user authentication, ensuring secure payments and smart user identification throughout the charging process
INSTALLATION EFFICIENCY
-
Integrated design simplifies installation and saves space
-
With only one unit to maintain, it reduces installation and maintenance costs while improving system stability
DYNAMIC LOAD BALANCE
-
Advanced load distribution technology flexibly adjusts current and power based on demand, ensuring efficient resource utilization for both small-scale commercial sites and large fleet operations.
